Deckma Hamburg OMD-24
Environmental protection is one of the highest priorities in the maritime industry, making reliable bilge monitoring essential for every vessel. The OMD-24 Bilge Alarm System is a highly trusted 15 PPM Bilge Alarm designed to continuously monitor oil concentration in bilge water discharged through the Oily Water Separator (OWS). Fully compliant with IMO Resolution MEPC.107(49) and MARPOL Annex I, the OMD-24 helps vessels meet international environmental regulations while ensuring safe and efficient engine room operations.
Swift Marine Tech Services Pte Ltd provides complete technical support for the OMD-24 Bilge Alarm, including inspection, calibration, troubleshooting, repair, retrofit, commissioning, spare parts supply, measuring cell maintenance, sensor replacement, onboard servicing, and remote technical assistance. Our experienced marine engineers support commercial vessels, offshore units, tankers, bulk carriers, container ships, naval vessels, and passenger ships worldwide.
OMD-24 Bilge Alarm System – Professional 15 PPM Bilge Alarm Services for IMO Compliance
The OMD-24 Bilge Alarm is an advanced marine oil content monitor that continuously measures the oil concentration in water discharged from an Oily Water Separator (OWS). When the oil content exceeds the preset alarm level—typically 15 ppm—the system immediately activates alarms and initiates automatic discharge control to prevent marine pollution.
The OMD-24 delivers fast response times, high measurement accuracy, and stable operation even in harsh engine room environments. It is widely installed on vessels requiring reliable bilge monitoring and compliance with IMO environmental regulations.
In addition to its dependable monitoring performance, the OMD-24 is designed for easy maintenance and integration with shipboard systems, making it a practical choice for vessel operators who need consistent compliance, reduced downtime, and long-term operational reliability.
Key Features of the OMD-24 Bilge Alarm
Accurate 15 PPM Oil Content Monitoring
The OMD-24 continuously measures oil concentration from 0–30 ppm, with adjustable alarm settings from 1–15 ppm, ensuring precise monitoring of bilge water discharge.
Fast Response for Enhanced Safety
Designed for rapid detection, the system delivers detector response in less than 5 seconds, helping maintain the overall IMO-required response time of under 20 seconds.
Intelligent Alarm and Fault Monitoring
The system continuously performs self-diagnostics to ensure dependable operation.
Features include:
- Adjustable alarm settings (1–15 ppm)
- Dual independent relay outputs
- Visual LED status indication
- Automatic fault detection
- Continuous oil concentration monitoring
- High measurement stability
Marine-Grade Construction
The OMD-24 is engineered specifically for demanding marine environments and includes:
- IP65 protection
- Corrosion-resistant anodized aluminum measuring cell
- Stainless steel sample connections
- Rugged marine electronics
- Compact installation design
- Long service life
Automation System Integration
The optional 0/4–20 mA analog output enables seamless integration with:
- Ship automation systems (AMS)
- Engine monitoring systems
- Alarm management systems
- Data logging equipment
- Remote monitoring solutions
- Integrated bridge monitoring systems
International Certifications & Compliance Standards
The OMD-24 Bilge Alarm System is designed to support vessels operating under strict international marine regulations and certification requirements. It is widely used as part of compliant oily water separator arrangements and helps shipowners maintain documentation for inspections, audits, and port state control checks.
Recognized International Standards and Compliance
- IMO Resolution MEPC.107(49)
- MARPOL Annex I
- 15 PPM Bilge Alarm Compliance
- Marine Environmental Protection Requirements
- Shipboard Oil Content Monitoring Standards
Where required, Swift Marine Tech Services Pte Ltd can assist with technical documentation, calibration support, functional testing, and onboard verification to help maintain compliance with international marine certification and inspection standards.
OMD-24 Technical Specifications
| Specification | Details |
|---|---|
| Measuring Range | 0–30 ppm |
| Alarm Range | 1–15 ppm Adjustable |
| Standard Alarm Setting | 15 ppm |
| Power Supply | 24V AC/DC |
| Power Consumption | Less than 5 VA |
| Sample Flow Rate | 0.1–4 L/min |
| Relay Outputs | 2 Independent Alarm Relays |
| Analog Output | 0/4–20 mA |
| Protection Rating | IP65 |
| Ambient Temperature | +1°C to +55°C |
| Sample Temperature | +1°C to +65°C |
Add Your Heading Text Here
Why Choose Swift Marine Tech Services Pte Ltd?
Ship owners and marine operators trust Swift Marine Tech Services Pte Ltd because we provide dependable, end-to-end support for OMD-24 Bilge Alarm systems and other marine monitoring equipment. Our team understands the importance of accurate 15 PPM bilge alarm performance, especially in demanding shipboard environments where compliance, safety, and uptime are critical.
From routine calibration and preventive maintenance to urgent troubleshooting and onboard repair support, we help ensure your bilge alarm system operates reliably and meets IMO and MARPOL requirements. Whether your vessel needs technical inspection, spare parts replacement, or assistance with marine automation integration, we deliver practical solutions that minimize downtime and keep operations running smoothly.
Our services include:
- Experienced marine service engineers
- Fast worldwide technical support
- Professional calibration services
- Genuine marine spare parts
- Comprehensive troubleshooting expertise
- Marine automation integration
- Preventive maintenance programs
- Cost-effective repair solutions
- Quick response for vessel emergencies
- Reliable after-sales technical support
We combine technical expertise with responsive service to support vessel owners, ship managers, and marine engineers across a wide range of vessel types. Our objective is to help vessels remain fully compliant with IMO and MARPOL regulations while ensuring dependable bilge monitoring, accurate oil content detection, and reduced operational downtime.
Contact Swift Marine Tech Services Pte Ltd
Need professional support for your OMD-24 Bilge Alarm System?
Swift Marine Tech Services Pte Ltd provides expert inspection, troubleshooting, calibration, commissioning, repair, retrofit, maintenance, spare parts supply, and technical support for OMD-24 and other marine 15 PPM Bilge Alarm Systems. Contact our marine specialists today for fast, reliable service that keeps your vessel compliant and operating safely.
